MS-7120
MASUNG
QR Code Scanning Module MS-7120N
MASUNG 2D Code Scanner
1.Comprehensively read all mainstream 1D and 2D codes, multi-language information barcode direct transmission
2. Object self-sensing, 2M/S motion tolerance, support for sunlight reading
3. Built-in RS232 and USB interface, through the code can be switched to switch
4.3.3-5V wide voltage input, no fear of voltage fluctuations
5. Large scanning window & ultra-thin lacquer fashion design
6.Read hand paper and electronic screen code at high speed.
Features:
Image(Pixels) | 640 pixels(H)*480 pixels(V) |
Light Source | Illumination: 6500K LED |
Minimum Resolution | ≥3.9 mil |
Voltage | 3.3-5VDC |
Working Current | 200mA |
Standby Current | 90mA |
Peak Current | 300mA |
Interfaces | USB, RS232 |
1D | UPC, EAN, Code 128, Code 39, Code 93, Code 11, Matrix 2 of 5, Codabar Interleaved 2 of 5, Mis Plessey, GSI DataBar, China Postal, Korean Postal , etc |
2D | PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec Hanxin, etc |
QR Code Scanning Module MS-7120N
MASUNG 2D Code Scanner
1.Comprehensively read all mainstream 1D and 2D codes, multi-language information barcode direct transmission
2. Object self-sensing, 2M/S motion tolerance, support for sunlight reading
3. Built-in RS232 and USB interface, through the code can be switched to switch
4.3.3-5V wide voltage input, no fear of voltage fluctuations
5. Large scanning window & ultra-thin lacquer fashion design
6.Read hand paper and electronic screen code at high speed.
Features:
Image(Pixels) | 640 pixels(H)*480 pixels(V) |
Light Source | Illumination: 6500K LED |
Minimum Resolution | ≥3.9 mil |
Voltage | 3.3-5VDC |
Working Current | 200mA |
Standby Current | 90mA |
Peak Current | 300mA |
Interfaces | USB, RS232 |
1D | UPC, EAN, Code 128, Code 39, Code 93, Code 11, Matrix 2 of 5, Codabar Interleaved 2 of 5, Mis Plessey, GSI DataBar, China Postal, Korean Postal , etc |
2D | PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec Hanxin, etc |
