Welcome to MASUNG TECHNOLOGY (HONGKONG) CO.,LIMITED
Availability: | |
---|---|
Quantity: | |
MS-MA90
MASUNG
1.Easy to embed into any type of self-service machine, instrument
2. Opening method: with lock or push button
3. Paper removal reminder function: paper removal detection + flashing light
4. Paper end reminder function: paper end detection
5. Automatic knife jam removal function: automatic knife retraction after power on after shutdown
MS-MA90 has been tested by the market and has high applicability. It can be easily embedded in various self-service devices. In terms of printing paper width, MS-MA90 has two printing paper widths to choose from. You can choose 80mm or 58mm width paper rolls for printing. The effective printing speed can reach up to 72mm, and the maximum printing speed is 150mm/s, which is enough to meet the needs of most application scenarios. In terms of paper cutting, MS-MA90 also has two paper cutting methods, half-cutting and full-cutting, which can be freely selected. Half-cutting means that the cutter does not cut completely after printing and needs to be torn off by hand. It is generally suitable for scenarios where customers do not necessarily need receipts. Full-cutting means cutting all of the paper, which is suitable for scenarios where customers must need receipts.
1. The cover open sensor can be used to detect whether the printer is in the cover open state, which can prevent forgetting to close the printer or the printer cover is not closed.
2. The paper end sensor can detect the paper reserve and give a prompt when the paper roll is about to run out, so as to prepare the paper roll in advance and avoid the gap time of ticket printing caused by lack of paper.
3. When there is no paper, the paper end sensor can issue a warning to remind the staff to change the paper roll.
4. The black mark paper sensor can detect the printing paper roll with black mark, so that the printer can adjust the printing length according to the black mark when printing.
Model | MS-MA90 |
Paper width | 80/58mm |
Printing speed | 150 mm/s(max) |
Printing Width | 72mm(max) |
Cutting Method | Sliding |
Cutting Conditions | Full/Partial(optional) |
Cutting Thickness | 60 - 120 um |
Working Voltage | DC12 ± 10% V |
Peak Current | 12V/10A |
Weight | About 0.45kg(without Paper Roll) |
Interface | Serial,USB,Cash box |
Mechanical Life | 100 km |
Max Paper roll diameter | 80 mm |
Dimension(W*D*H) | W115mm * D85mm * H132mm |
RoHS
FCC
