Features: * Large scan window, piano baking paint appearance; * Perfect compatibility of paper electronic screen; * object self-sensing, large perspective image sensor; * Support backless screen bar code reading image sensor; * Built-in RS232 and USB interface; * Fast reading of paper and electronic screen codes, high motion tolerance; * Support 1D & 2D code; Multi-language bar code information direct transmission;
Model
MS-7120
Dimensions
67mm*67mm*35mm
Weight
145.5g
Voltage
3.3-5VDC
Interfaces
USB/ RS232
1D
UPC, EAN, Code 128, Code 39, Code 93, Code 11, Matrix 2 of 5, Codabar Interleaved 2 of 5, Mis Plessey, GSI DataBar, China Postal, Korean Postal , etc
2D
PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec Hanxin, etc.
Operating Temperature
-30°C to 70°C
Scan Angle Roll/Pitch/Skew
360°, ±65°, ±60°
Shock Specifications
Designed to withstand 1.5m(5') drops
